Scheda tecnica

---

Gas	Option
Welding range	M3 to M24, dia. 2 to 22 mm
Welding material	Mild steel, stainless steel, aluminum
Welding rate	Dia. 22 = 6 studs/min
Welding current	2,000 A (max.)
Current adjustment range	300 to 2,000 A (stepless)
Primary power	400 V, 3 phases, 50/60 Hz, 63 AT (alternative input voltages available)
Primary plug	63 A (with 400 V mains)
Connected load	100 KVA (with 400 V mains)
Cooling type	F (temperature controlled cooling fan)
Protection class	IP 23
Operational and storage conditions	According to current standards
Dimension L x W x H	600 x 500 x 830 mm (without handle)
Weight	95 kg
Order N°	93-60-2201 93-60-2202 (Gas)
