Scheda tecnica

---

Gas	Option
Welding range	M3 to M24, dia. 2 to 25 mm
Welding material	Mild steel, stainless steel, aluminum
Welding rate	Dia. 25 = 6 studs/min
Welding current	2,600 A (max.)
Current adjustment range	300 to 2,600 A (stepless)
Welding time	5 to 1,500 msec (stepless)
Primary power	400 V, 3 phases, 50/60 Hz, 63 AT at 2 studs/min dia. 25 mm (more than 2 studs/min 125 AT) (alternative input voltages available)
Primary plug	63 A (with 400 V mains)
Cooling type	F (temperature controlled cooling fan)
Protection class	IP 23
Operational and storage conditions	According to current standards
Dimension L x W x H	650 x 560 x 1,290 mm (without handle)
Weight	160 kg
Order N°	93-60-3211 (1 Gun connection)
