Scheda tecnica

---

Welding range	2 x M3
Stud material EN ISO 13918	4.8 copper-plated steel, A2-50 stainless steel
Weld frequency	1 to 2 double seams per minute
Capacity	80,000 µf
Energy	325 Ws
Voltage	Max. 90 V
Energy source	Capacitors
Charging time of capacitors	about 30 sec.
Battery	12 V, 5 Ah (discharge test)
Battery capacity	200 double welds from M3
Charging time of the battery	Max. 10 hours
Battery life	Min. 200 charging cycles; (no warranty on batteries)
Distance between the studs	Distance adjustment from 25 mm to 61 mm (19 mm on request)
Connecting cable	1.5 m
L x W x H Dimensions	360 x 135 x 210 mm
Gun size L x W x H	165 x 25 x 95 mm
Weight	7 kg (including gun)
Gun weight	550 g
Order N°	92-10-2280
