Fully automatic power supply
For welding studs with flanges, in accordance with current regulations.
Fully automatic power supply
For welding studs with flanges, in accordance with current regulations.
Stud diameter | M3 to M8, dia. 3 to 8 mm (other diameters on request) |
Stud length | 8 to 50 mm |
Feeding speed | Up to 30 pins/min (depends on stud and feed pipe) |
Compressed air connection | 6 bar/800 liters/min |
Electricity supply | 230 V, 50 Hz, 0,9 A (alternative voltage inputs available) |
Degree of protection | IP 20 |
L x B x H Dimensions | 470 x 310 x 280 mm |
Weigth | About 24 kg |
Order N° | 94-63-103B (per dia. 3 mm) 94-63-104B (per dia. 4 mm) 94-63-105B (for dia. 5 mm) 94-63-106B (per dia. 6 mm) 94-63-171B (per dia. 7,1 mm) 94-63-108B (per dia. 8 mm) 94-63-153B (for pins with coarse thread dia. 5) 94-63-163B (for pins with coarse thread dia |
