Stud welding gun
For ARC welding, in accordance with current regulations.
| Welding range | M3 to M12, dia. 2 to 12 mm |
| Stud length | 10 to 400 mm (depending on tripod) |
| Stud material | Mild steel, stainless steel |
| Stud type | Any type or shape (special chucks if required) |
| Length compensation | 3 mm automatic |
| Stroke | Adjustment range 3 mm, lockable |
| Spring pressure | Adjustable, arresting |
| Welding cable | 5 m |
| Insulation class | IP 20 |
| Workplace noise level | Up to 90 dB (A) may occur during welding |
| Operational and storage conditions | According to current standards |
| Dimension L x W x H | 200 x 65 x 140 mm (without cable, with foot piece) 0.8 kg (without cable) |
| Weight | 0.8 kg (without cable) |
| Order N° | 93-20-270 (gun with bushing for support rods) 93-40-021 (complete gas support) 93-40-022 (complete ceramic nozzle holder (CF) |
