Scheda tecnica

---

Welding range
Stud length	10 to 390 mm (depending on tripod)
Stud material	Mild steel, stainless steel
Stud type	Any type or shape (special chucks if required)
Length compensation	9 mm automatic
Stroke	Adjustment range 6 mm, (0.25 mm steps, arresting)
Damping	Adjustable oildamper
Insulation class	4.85 m, 95 mm²
Workplace noise level	Up to 90 dB (A) may occur during welding
Operational and storage conditions	According to current standards
Dimension L x W x H	260 x 74 x 220 mm (without cable, with foot piece)
Weight	2 kg (without cable)
Order N°	93-20-290
