Scheda tecnica

---

Welding range	Dia. 14 to 25 mm
Stud length	10 to 390 mm (depending on tripod)
Stud material	Mild steel, stainless steel
Stud type	Any type or shape (special chucks if required)
Length compensation	9 mm automatic
Stroke	Adjustment range 6 mm, (0.25 mm steps, arresting)
Damping	Adjustable oildamper
Welding cable	1.5 m, 120 mm²
Insulation class	IP 20
Workplace noise level	Up to 90 dB (A) may occur during welding
Operational and storage conditions	According to current standards
Dimension L x W x H	260 x 74 x 220 mm (without cable, with foot piece)
Weight	2 kg (without cable)
Order N°	93-20-295
