Scheda tecnica

---

Suitable welding machine	IT 1002
Welding technique	Rotating arc MARC
Welding range	HexNut type M6-M12 slag nuts
Sheet thickness	from 1 to 3 mm/0,04
Material to weld element	A2-50
Type of element to weld	MARC nuts - HexNut type
Welding frequency	up to 4 nuts/min. The maximum welding frequency is limited by certain parameters.
Length compensation	3/0,12
Race	Adjustment radius 3/0,12
Shock absorber	Adjustable, with stop
Solder cable	5 m / 16,40'
IP code	IP 20
Noise level at the workplace	Up to 90 dB(A) possible during welding
Dimensions LxWxH	320x70x200 mm/12,60
Weight	0.9 kg/ 1.98 lbs (without cable)
Order N°	93-20-242
