Scheda tecnica

---

Welding range	M3 to M8, dia. 2 to 8 mm (other dimensions on request)
Stud length	6 to 40 mm, longer studs can be welded with optional accessories
Stud material	Mild steel, stainless steel
Stud type	Any type or shape (special chucks if required)
Spring pressure	Adjustable, arresting
Welding cable	6.5 m
Insulation class	IP 20
Workplace noise level	> 90 dB (A) may occur during welding
Operational and storage	According to current standards
Dimension L x W x H	170 x 40 x 140 mm (without cable)
Weight	0.5 kg (without cable)
Order N°	92-20-256
